Researchers from the University of California, Berkeley (UC Berkeley) have unveiled a groundbreaking solution to a long-standing challenge in the study of two-dimensional (2D) materials.
Study: A smoother way to study “twistronics. Image Credit: Production Perig/Shutterstock.com
The team introduced a micro-electro-mechanical system-based generic actuation platform for 2D materials (MEGA2D), which enables precise control of the twist angle in materials like graphene. This innovative micro-electromechanical system (MEMS) simplifies twistronics research by eliminating the need for individually fabricated devices, paving the way for advances in optics, transistors, and quantum computing.
Related Work
Research on two-dimensional (2D) materials has advanced significantly since the discovery of magic-angle graphene superlattices, which revealed superconductivity at specific twist angles. This breakthrough gave rise to the field of twistronics, prompting further investigations into the electronic, optical, and mechanical properties of twisted 2D materials.
To overcome the challenges of replicating precise twist angles, innovations like the MEGA2D platform were developed. These MEMS-based tools have enabled more efficient and scalable studies of 2D material properties, with promising applications in areas such as quantum computing and photonics.
Advances in Twistronics Technology
Six years ago, a groundbreaking discovery revealed that ultra-thin, slightly misaligned carbon layers could become superconductors when their twist angle was precisely adjusted. This revelation led to the emergence of "twistronics," a field that has captivated researchers and paved the way for exploring new electronic phases in 2D materials with significant technological potential.
Building on these discoveries, Harvard researchers developed a novel method to study twisted materials, streamlining the process of twisting and analyzing various types. This innovation promises breakthroughs in quantum computing, transistors, and optical devices by offering an efficient way to manipulate the unique properties of 2D materials.
The researchers introduced a fingernail-sized device capable of precisely twisting thin layers of 2D materials, replacing the labor-intensive process of fabricating each twisted device individually. This new tool enables continuous twisting, facilitating the exploration of various 2D materials. It could significantly enhance technologies such as transistors and solar cells, while also advancing research in quantum computing.
Harvard physicists emphasized the importance of this device, which enables precise control over both electron density and twist angle in 2D materials. This dual control opens up numerous opportunities for discovering and studying new phases of matter in low-dimensional materials.
Earlier, the creation of twisted bilayer graphene was a major breakthrough, but replicating the twist angle posed a significant challenge. Each device required meticulous fabrication, making the process time-consuming and difficult to scale.
This frustration led to the idea of developing "one device to twist them all," inspiring the researchers to create a micromachine capable of twisting two layers of material on demand. The resulting device, MEGA2D, eliminates the need to produce hundreds of unique samples and provides a general solution for manipulating a wide range of 2D materials—not just graphene.
Developed through a collaboration between the Yacoby and Mazur labs at Harvard, the MEGA2D platform offers researchers a versatile tool for studying various material systems. It allows for precise control of the twist angle, enabling scientists to explore materials that were previously too difficult or time-consuming to investigate.
The effectiveness of MEGA2D was demonstrated by twisting two layers of hexagonal boron nitride, a material related to graphene, and examining the optical properties of the resulting bilayer. This revealed quasiparticles with desirable topological characteristics, suggesting the potential use of twisted hexagonal boron nitride in developing light sources for low-loss optical communication systems.
An assistant professor at the University of California, Berkeley, emphasized the significance of the MEGA2D device, noting its ability to help the research community more efficiently tackle unresolved challenges in twisted graphene and other 2D materials.
The MEGA2D platform is expected to drive discoveries across diverse scientific fields, including condensed matter physics and materials science. Developing this device was not without its challenges; researchers encountered difficulties in achieving real-time control of 2D material interfaces, requiring nearly a year of experiments and multiple failed attempts before finding success.
The breakthrough occurred after extensive refinement of the MEMS design in Harvard's cleanroom, with support from the Center for Nanoscale Systems. Although integrating MEMS technology with bilayer structures proved complex, it ultimately opened new avenues in optics and photonics.
By tuning the nonlinear response of these twisted devices, researchers gained valuable tools for advancing the study of 2D materials. This progress holds promise for various applications, including quantum computing and next-generation photonics.
Conclusion
In summary, a groundbreaking discovery six years ago revealed that ultra-thin carbon layers could become superconductors by adjusting their twist angle, giving rise to the field of twistronics. Researchers have since developed the MEGA2D micromachine, enabling precise control over the twisting of 2D materials and unlocking their potential for applications in transistors, optical devices, and quantum computing.
The team demonstrated the device’s effectiveness with hexagonal boron nitride, revealing quasiparticles with valuable topological properties. This innovation opens the door to efficiently exploring new material properties and phases.
