Enhancing the Performance of Quantum Dot Intermediate Band Solar Cells

By Samudrapom DamReviewed by Susha Cheriyedath, M.Sc.Apr 15 2024

An article published in the journal Symmetry highlights significant performance enhancements in indium arsenide/gallium arsenide (InAs/GaAs) quantum dot intermediate band solar cells (IBSC) through precise optimization of QD dimensions.

Quantum Dot Intermediate Band Solar Cells (QD-IBSCs)

IBSCs have demonstrated significant potential in improving efficiency and increasing light absorption. IBSCs exploit the sub-bandgap photon absorption ability, transitioning electrons from the valence band to the intermediate band before finally transitioning them from the intermediate band to the conduction band.

The integration of QDs into the active layers of these solar cells extends the range of absorbed sub-bandgap photons, significantly increasing absorption possibilities. This broadened spectrum leads to enhanced cell efficiency by modifying the bandgap.

Particularly, structures like InAs/GaAs and InAs/AlGaAs utilize QDs to form the intermediate band in QD-IBSCs. Among various QD shapes—cylindrical, spherical, and pyramidal—cylindrical QDs have shown superior performance. They are notably less sensitive to the angle of incident light, which results in higher absorption rates and stable efficiency across various light conditions. Research has consistently demonstrated that cylindrical QDs maintain robust absorption characteristics at multiple angles of incidence.

Despite these advancements, challenges remain in optimizing the placement and size of QDs within the solar cells to maximize efficiency and light absorption. Continued efforts in engineering and material science are critical to leveraging the unique electronic properties of QDs and achieving optimal performance in solar cell applications.

The Proposed Approach

In this study, researchers conducted a theoretical investigation of InAs/GaAs QD-IBSC utilizing cylindrical quantum dots. The primary goal was to determine how factors such as the positioning and dimensions of the quantum dots, as well as the spacing between adjacent dots, influence light absorption and overall cell efficiency.

The research focused on identifying optimal conditions for these quantum dots in terms of their height, size, shape, and placement. These parameters were evaluated for their potential to enhance the cell’s output power, electron-hole generation rate, and short-circuit current. The process began with establishing baseline conditions using a reference cell, followed by iterative adjustments to the quantum dots’ characteristics to determine conditions that most effectively improved efficiency.

Detailed analyses were performed at over 500 frequency points to optimize these parameters under three specific conditions: maximizing the generation rate, the short-circuit current, and the output power. It was observed that modifications in quantum dots’ dimensions—such as height, radius, and volume—significantly impact various cell characteristics, affecting both the optical and electronic properties of the cell.

Significance of the Work

This research provides key insights into the optimization of QD-IBSCs, exploring various conditions to enhance solar cell efficiency through advanced quantum dot configurations. By systematically altering and testing the parameters of the quantum dots, the study achieves significant improvements in power absorption, short-circuit current density, and generation rate. Below are the detailed findings from these three crucial aspects of the study:

1. Power Absorption Optimization-Based Improvement: Modifications to the electrical characteristics were induced by altering the QDs' parameters, with computations performed at 500 frequency points to maximize power output. Comprehensive analyses and modifications were conducted across different ranges for every influential parameter. The resulting optimized parameters and electrical characteristics included a QD radius (R) of 25 nm, pitch of cylindrical QDs (P) of 62.86 nm, height of cylindrical QDs (b) of 80 nm, active layer thickness (a) of 111.1 nm, and strain layer thickness (L) of 10.29 nm. These optimizations enhanced the solar cell's efficiency by up to 30.5 %.
2. Short-circuit Current Density Optimization-Based Improvement: The physical attributes of QDs, including radius, size, and density, were optimized to enhance solar cell output power and light absorption. This led to an increase in cell current. The optimized values were R = 25 nm, P = 71.2 nm, b = 80 nm, a = 96.36 nm, and L = 10.07 nm, achieving an efficiency of 34.30 %.
3. Generation Rate Optimization-Based Improvement: Optimal conditions for maximizing the generation rate were achieved by fine-tuning QD features. The optimized values were R = 10 nm, P = 30 nm, b = 28.52 nm, a = 40 nm, and L = 6.51 nm, resulting in an efficiency of 32.34 %.

In all three conditions, the impact of size variations, QD height and radius, and layout within the active layer on efficiency was evident. Moreover, the QD pitch improved the solar cell characteristics, while the active layer thickness optimization in QD-IBSC increased the overall cell efficiency and the short-circuit current.

Among the three unique conditions considered in this work, the maximum efficiency was achieved in the condition of maximum short-circuit current, which led to enhanced cell performance compared to other conditions. Specifically, 34.3 % efficiency and 38.42 mA/cm² short-circuit current density were achieved under short-circuit current density optimization, which represented a substantial improvement compared to the values attained by the reference cell.

To summarize, this study's findings demonstrated that optimizing the size and placement of QDs within the IBSCs could effectively enhance overall solar cell efficiency.

Journal Reference

Farhadipour, F., Olyaee, S., Kosarian, A. (2024). Theoretical Investigation and Improvement of Characteristics of InAs/GaAs Quantum Dot Intermediate Band Solar Cells by Optimizing Quantum Dot Dimensions. Symmetry, 16(4), 435. https://doi.org/10.3390/sym16040435, https://www.mdpi.com/2073-8994/16/4/435
