Black holes unleash powerful jets of radiation and particles, believed to be a source of cosmic rays [1]. Astrophysicists worldwide study these jets, using advanced imaging techniques and precise computer simulations to unravel their mysteries.
Image Credit: Mark Ward/Shutterstock.com
What are Black Hole Jets?
As stated above, relativistic jets lead to the emission of particles and radiations. Drawn by the intense gravitational force of the black hole, matter is strongly attracted toward its center as it consumes surrounding gas and dust. However a small portion of particles become accelerated to velocities close to the speed of light and are ejected in two narrow beams along the black hole's axis of rotation.
The astrophysical jets from black holes are a commonly observed phenomenon in high-energy particle physics. It is frequently hypothesized that these jets are initiated by large-scale magnetic fields, originating either from the inner region of an accretion disc or from the rotation of the black hole itself [2].
The most energetic astrophysical jets are commonly linked to black holes surrounded by rotating disks of ionized matter, known as accretion disks, within relatively strong large-scale magnetic fields. These magnetic fields are prevented from escaping to infinity by the ionized matter, while the gravitational pull of the central compact object retains the matter within its vicinity.
These large-scale magnetic fields extract rotational energy from both the black hole and the surrounding disk. The process involves mechanisms such as centrifugal slingshots or magnetic 'springs' within the accretion disk. Such phenomena are integral to the evolution of black hole jets [3].
Latest Imaging of Black Hole Jets
Recent research has led to the successful imaging of supermassive black holes along with their powerful jets. A prime example is the massive black hole situated in the center of the galaxy named Messier 87 [4].
Researchers conducted very-long-baseline interferometry (VLBI) observations of M87, yielding maps that depicted a triple-ridged jet originating from a spatially resolved radio core. This core manifested as a faint ring, featuring two regions of increased brightness in the northward and southward segments [5].
The fine-scale structure observed at the base of the M87 jet was significantly different from the typical morphology of radio-loud active galactic nuclei. Traditionally, these nuclei are marked by a compact, unresolved core, giving rise to a bright, directed plasma jet that extends downstream.
In addition to the jet, Radiatively Inefficient Accretion Flow (RIAF) simulations have revealed the presence of high-mass loaded, gravitationally unbound, and non-relativistic winds. These winds are propelled by a combination of centrifugal force and magnetic pressure, constituting a vital element in shaping the jet into a parabolic form.
In another exciting development, the Event Horizon Telescope collaboration, which includes researchers from the Max Planck Institute for Radio Astronomy in Bonn, Germany, has achieved a breakthrough by resolving the base of an evolving plasma jet with ultra-high angular resolution. This international team utilized a telescope the size of Earth to investigate the magnetic structure within the nucleus of the radio galaxy 3C 84 (Perseus A), which is among the nearest active supermassive black holes [6].
In addition to capturing the first images of black holes, the Event Horizon Telescope (EHT) is well-suited to observe astrophysical plasma jets and their interaction with strong magnetic fields. Recent findings offer insights into the process of mass accretion onto supermassive black holes, which occurs through advection. According to this model, the infalling matter forms a highly magnetized disk known as a magnetically arrested disc (MAD). Within this setup, the magnetic field lines become tightly wound and twisted, hindering the efficient release of magnetic energy. Moreover, studies suggest that the black hole 3C 84 is rapidly rotating, indicating a connection between jet formation and large black hole spins.
Modeling and Simulation Advancements for Understanding Black Hole Jets
The prevailing consensus in the scientific community suggests that the formation of astrophysical jets requires a combination of magnetic fields and rotation. One of the most influential models, the Blandford-Znajek mechanism, proposes that jets are formed by extracting the spin energy of a black hole through magnetic field lines connected to its event horizon.
In a recent research study, scientists employed three-dimensional general relativistic magnetohydrodynamic (GRMHD) simulations to replicate the intricate structure of the jet observed in M87 and to evaluate its formation mechanism [7].
The researchers analyzed the electron distribution, encompassing both thermal and non-thermal components. Computational simulations demonstrated that MADs experience magnetic flux eruptions, where bundles of magnetic flux with intense vertical fields break free from the black hole's magnetosphere and spread radially outward into the disk.
The results of this advanced simulation bridge the gap between jet formation models and observational data. They highlight the effectiveness of the Blandford-Znajek model and magnetic reconnection as key mechanisms driving electron acceleration in jets.
Gas falling into a black hole from considerable distances does not perceive the black hole spin direction, leading to an anticipated prevalence of misalignment between the accretion disc and black hole spin. However, the dynamics of tilted discs, such as angular momentum transport and jet formation, remain poorly understood till now.
Impact of Black Hole Jets on Star Formation in Galaxies
The jets emitted by actively accreting black holes can induce significant outflows in galaxies, potentially influencing star formation by either rarefying or compressing clouds of molecular gas. Experimental data from the Atacama Large Millimeter Array (ALMA) and the Very Large Telescope (VLT) operated by the European Southern Observatory (ESO) was used by researchers to thoroughly investigate the gas pressure and examine the effects of the black hole jets on the conditions conducive to star formation within interstellar clouds [9].
The European research team conducted astrochemical, thermally balanced, and radiative transfer modeling of the CO and HCO+ emission within the galaxy IC 5063. The analysis revealed that mechanical heating from jets and cosmic rays associated with the galaxy contributes significantly to the heating rate of molecular gas, potentially sustaining it singlehandedly. As a result, clouds influenced by these mechanisms exhibit temperatures and densities indicative of a substantial increase in internal pressure. These results indicate that certain clouds experience rarefaction while others undergo compression. This experimental study offers a novel perspective on the potential connections between galactic outflows and the conditions for star formation, emphasizing observable pressure gradients and the role of supermassive black hole jets in star formation.
Black hole jets are not just mere bursts of radiation and particles; they play a crucial role in achieving a thorough understanding of the astrophysical phenomena taking place in our universe and cosmic evolution. With the recent breakthroughs in the imaging and modeling of these jets, scientists have gained a much better understanding of star formation and the magnetic properties of galaxies. With the improvements in telescopes and imaging algorithms, many advancements are expected in this exciting field of study.
Ready to meet the a weird alternative to black holes?
Further Reading
- NuSTAR, California Institute of Technology. (2024). Relativistic Jets. (Online). Available at: https://www.nustar.caltech.edu/page/relativistic_jets
- [Accessed on 05 April 2024].
- Parfrey, K. et. al. (2015). Black hole jets without large-scale net magnetic flux. Monthly Notices of the Royal Astronomical Society: Letters, 446(1), L61-L65. Available at: https://doi.org/10.1093/mnrasl/slu162
- Contopoulos, I. et. al. (2015). The formation and disruption of black hole jets (Vol. 414). Berlin: Springer. Available at: http://dx.doi.org/10.1007/978-3-319-10356-3
- Anderson, P. (2023). Black hole and its jet imaged together for 1st time. EarthSky. (Online). Available at: https://earthsky.org/space/black-hole-jet-1st-image-messier-87/
- [Accessed on 06 April 2024].
- Lu, R. et al. (2023). A ring-like accretion structure in M87 connecting its black hole and jet. Nature 616, 686–690. Available at: https://doi.org/10.1038/s41586-023-05843-w
- Max-Planck-Gesellschaft. (2024). Magnetic launching of black hole jets in Perseus A. (Online). Available at: https://www.mpg.de/21486001/magnetic-launching-of-black-hole-jets-in-perseus-a
- [Accessed on 06 April 2024].
- Yang, H. et. al. (2024). Modeling the inner part of the jet in M87: Confronting jet morphology with theory. Science Advances, 10(12), eadn3544. Available at: https://doi.org/10.1126/sciadv.adn3544
- Liska, M. et. al. (2018). Formation of precessing jets by tilted black hole discs in 3D general relativistic MHD simulations. Monthly Notices of the Royal Astronomical Society: Letters, 474(1), L81-L85. Available at: https://doi.org/10.1093/mnrasl/slx174
- Dasyra, K. et al. (2022). Insights into the collapse and expansion of molecular clouds in outflows from observable pressure gradients. Nat Astron 6, 1077–1084. Available at: https://doi.org/10.1038/s41550-022-01725-9
